6 Axis Robotic Screwdriver Machine Double XYZ Screwdriver Machine
6 Axis Robotic Screwdriver Machine Description:
A 6-Axis Robotic Screwdriver Machine is an advanced automation system that integrates a 6-degree-of-freedom robotic arm with a high-precision electric or pneumatic screwdriver. It is designed to automatically pick, align, and fasten screws into products or assemblies with speed, consistency, and repeatable accuracy.
6 Axis Robotic Screwdriver Machine Features:
- 6 Axes, suitable for 2 different screws locking at the same time.
- Solid frame to ensure stable and precise locking.
- Adjustable height for feeder and Z axis to support different height products.
- High speed motion card and touch screen for real time production.
- Intelligent detection of missing locks and slip teeth.
- Suitable for M1-M6 screws.
- Supports flat holes, deep holes, oblique holes, and different flat holes.
- Screw type: cross screw, torx, inner hexagon screw, outer hexagon screw, slotted screw, triangular screw, etc.
6 Axis Robotic Screwdriver Machine Specifications:
| Model |
SMTSD229 |
| Power Supply |
110VAC 60HZ |
| Air Pressure |
0.3-0.6Mpa |
| Power Rate |
1000W |
| Screw Spec |
M1-M6 |
| Locking Speed |
1-1.6 second/screw |
| Positioning Precision |
±0.02mm |
| Working Area |
250x200x100mm |
| Stroke |
X: 500mm, Y: 500mm, Z: 100mm |
| Moving Speed |
X: 800mm/s, Y: 600mm/s, Z: 800mm/s |
| Machine Dimension |
695x1030x750mm |
| Communication Port |
USB |
| Machine Weight |
150kgs |
6 Axis Robotic Screwdriver Machine Suitable Screws:
It is suitable for cross screw, torx, inner hexagon screw, outer hexagon screw, slotted screw, triangular screw, etc.
6 Axis Robotic Screwdriver Machine Applications:
It is suitable for screw locking of various electronic products, such as mobile phones, navigators, calculators, keyboards, tablet computers, LCD TVs, air ducts, LEDs, induction cookers, communications and other industries.
| Industry |
Application |
| Consumer Electronics |
Assembly of smartphones, tablets, laptops, and wearables. |
| Automotive |
Fastening parts in dashboards, ECUs, sensors, and lighting systems. |
| Home Appliances |
Assembling washing machines, microwaves, air conditioners. |
| Computers & Servers |
Screwdriving in power supplies, cases, and motherboard installations. |
| Medical Devices |
High-precision assembly of diagnostic tools, monitors, and enclosures. |
| Industrial Equipment |
Assembly of control panels, actuators, and mechanical housings. |
| Packaging & Logistics |
Screwing enclosures or mounts in automation systems. |
